ZEPRO Z 1500/2000/2500 tail lift for trucks

The ZEPRO Z 1500/2000/2500 is a leading heavy-duty cantilever tail lift with a load capacity of up to 2,500 kg, for trucks with a gross weight over 12 t.

SKU: ZEPRO-Z1500-2000-2500 Category: Tags: ,

The ZEPRO Z 1500/2000/2500 is a heavy-duty cantilever tail lift with a load capacity of up to 2,500 kg, intended for trucks with a gross weight over 12 t. It is the market leader for stable and reliable operation in demanding conditions.

A unique quick-opening solution saves operator time. Double-acting lifting and tilt cylinders ensure reliable operation in all conditions, including cold weather, and the control electronics are housed in the frame for easier servicing. The maximum lifting height is 1,710 mm for the 1,500 and 2,000 kg versions, and 1,500 mm for the 2,500 kg version.

  • ZEPRO Clearoil filter – clean oil, less wear and protection against freezing at low temperatures
  • Stainless steel protective plates – protect the platform coating
  • Yellow warning line – clearly marked platform edge
  • Side ramps and warning lights as accessories

Technical specifications Value
Load capacity (kg) 1500 – 2500
Platform aluminum, steel
Max. platform length (mm) 2205
Max. platform width (mm) 2580
Lift height (mm) 1300 – 1710
Number of versions 8
Available versions Z 1500-135, Z 1500-155, Z 1500-175, Z 2000-135, Z 2000-155, Z 2000-175, Z 2500-130, Z 2500-150

Detailed technical specifications for each version are available on request.
