ZEPRO Z 100 tail lift for trucks
The ZEPRO Z 100 is a slim and light cantilever tail lift with a load capacity of up to 1,000 kg, for trucks with a gross weight of 5 to 12 t – with an aluminum platform for a higher payload.
The ZEPRO Z 100 is a cantilever tail lift with a load capacity of up to 1,000 kg, intended for standard-duty trucks with a gross weight of 5 to 12 t. As a slim and light solution for mid-range vehicles, it preserves the maximum payload thanks to the aluminum platform.
A wide choice of mounting brackets allows fast and easy installation, and the light and flexible aluminum protective bumper is easily fitted to trucks of all sizes. Available in two versions, with a lifting height of 1,100 or 1,300 mm.
- Rollstops (wheeled cargo stops) – protection for goods and workers
- Additional control units – fixed, with coiled cable or radio
- Side ramps – loading from the side of the platform, and from a ramp or sidewalk
- Warning lights – switch on automatically when the platform is lowered to a horizontal position
- Radio control unit – compact and easy to install
| Technical specifications | Z 100-110 | Z 100-130 |
|---|---|---|
| Load capacity (kg) | 1000 | 1000 |
| Platform | aluminum | aluminum |
| Max. platform length (mm) | 1800 | 1800 |
| Max. platform width (mm) | 2580 | 2580 |
| Lift height (mm) | 1100 | 1300 |
Detailed technical specifications for each version are available on request.
